Despiece Martillo Yt24

Descripción

Estamos listos a escuchar tus requerimientos a fin de asesorarles de manera correcta, así entenderemos con claridad su necesidad y aplicar de la manera correcta. Buscando ser ágiles en nuestra respuesta para optimizar su necesidad.

Contáctanos: 3208103071 – 3103287545 . e-mail: comercial@mundodotaciones.com – Fijo: 6019700.

YT24-1.02 RATCHET YT240001 – YT24-1.03 VALVE CHEST YT240002
YT24-1.04 VALVE YT 24-28 YT240003 – YT24-1.05 VALVE COVER YT240004
YT24-1.06 SETTING PIN (VALVE PLUG) YT 28-24 YT280011 – YT24-1.07 RATCHET PAWL YT 28-24-20 YT280012
YT24-1.08 RIFLE NUT YT240005 – YT24-1.09 RIFLE BAR YT 28-24 YT280013
YT24-1.10 PISTON YT240006 – YT24-1.11A CYLINDER YT240007
YT24-1.12 GUIDE SLEEVE (GUIDE RING) YT240008 – YT28-1.13 MUFFLER YT 29-28-27-24 YT280008
YT24-2.01A FRONT HEAD YT240009 – YT24-2.02 ROTARY SLEEVE YT240010
YT24-2.03 SHANK SLEEVE (DRILL SLEEVE) YT 29-28-27-24-19 YT280017 – YT24-2.06 YOKE BOLT YT 28-24-18 YT280020
YT24-2.07A* YOKE YT 28-24-18 YT280021 – YT24-3.01 SPRING RING (ELASTIC RING) YT 29-28-24-18 YT280034
YT24-3.02 SIDE BOLT YT280024 – YT28-3.03A CONTROL VALVE YT 28-24 YT280025
YT24-3.04 WATER TUBE YT 29-28-27-24 YT280026 – YT24-3.05 AIR TUBE YT 29-28-24 YT280027
YT24-3.06 SMALL WASHER (SMALL SEAL SLEEVE) YT 29-28-27-24 YT280035 – YT24-3.07 BIG SEAL SLEEVE YT 29-28-27-24-20-19-18YT280028
YT24-3.08 BACK HEAD (HANDLE) YT240014 – YT24-3.09 SIDE BOLT NUT (HEX THICK NUT)YT 29-28-27-24-19 YT280036
YT24-3.10 STEEL WIRE RING CLAMP (RETAINING RING) YT280037 YT 28-24 – YT24-3.12 TRIGGER YT 28-24 YT280039
YT24-3.15 CHANGE OVER VALVE YT 28-24 YT280040 – YT24-3.16 SPRING YT 28-24 YT280041
YT24-3.19 STEEL WIRE RING CLAMP (RETAINING RING) YT280043 YT 28-24-20 – YT24-3.21 CONTROL HANDLE YT 24-20 YT240015
YT24-3.22 FIXING PIN (TIGHT PIN) YT 28-24-20-19 YT280044 – YT24-3.23 WATER VALVE SET YT 28-24 YT280045
YT24-3.24 STEEL WIRE RING CLAMP(RETAINING RING) YT280046 YT 28-24-20 – YT24-3.25A SPRING CAP YT 28-24 YT280047
YT24-3.26 WATER VALVE YT 28-24 YT280048 – YT24-3.27 LEFT HANDLE YT240016
YT24-3.28 RIGHT HANDLE YT 28-24 YT280049 – YT24-3.29 RUBBER HANDLE (RUBBER COVER HANDLE) YT280050 YT 29-28-27-24-20
YT24-3.30 SEAL RING (SEAL BUSHING) YT28-24-20 YT280051 – YT24-1.15 CROWNED SPRING YT 29-28-27-24-20-19-18 YT280014

YT25-3.06 SPRING YT 29-28-27-24 YT280052 – YT25-3.09 WATER TUBE SLEEVE (WATER TUBE BUSHING) YT280053 YT 28-24-20
YT25-3.13 RUBBER PAD YT 29-28-27-24 YT280054 – YT25-3.14 AIR TUBE PAD YT 29-28-27-24 YT280055
YT25-3.20 SPRING YT 29-28-27-24-20-19-18 YT280056 – YT25-3.21 SETTING PIN YT 28-27-24-20-19-18 YT280057
YT25-3.24 O-SEAL RING (ORING) YT 29-28-24 YT280058 – YT25-3.35 PAD YT 29-28-27-24-20 YT28005
YT28-3.11 AIR CONNECTION TUBE (AIR PIPE EL BOW) YT280038 YT 28-24 – YT28-3.13 SWELL RING YT 29-28-27-24 YT280030
YT28-3.14 PRESSURE REGULATION VALVE YT 29-28-27-24 YT280031 – YT28-3.18 WATER CONNECTION TUBE YT 28-24 YT280042
YT28-2.05 YOKE SPRING (STEEL RETAINER SPRING) YT28-24 YT280019 – YT28-2.12 SPRING PAD (STEEL PAD) YT28-24 YT280018
ZBJ15 001-87 HOOP YT 29-28-27-24 -18-TPB 87 YT280064 – GB1235-76 ORING 8*1,91 YT 29-28-27-24 YT280060
GB1235-76 ORING 22*2,41 YT 28-24-18 YT280061 – GB1235-76 ORING 25*2,41 YT 29-28-27-24-18 YT280062
GB1235-76 ORING 36*3,51 YT28-24 YT280063 – GB879 8X24 SPRING PIN YT 29-28-27-24 YT280065
GB93 10 SPRING PAD (SPRING WASHER)YT 29-28-24-20-19-BYT 28-24 YT280066 – GB6172 M10-Zn.D HEX. THIN NUT (HEX LOKING NUT)NUT YT 29-28-24-20-19-BYT 28-24 YT280067
GB889M16Zn.D I-HEX.LOCKING NUT YT 28-24-20-19-18 YT280023
